PC370VM-IOT
Dell OptiPlex 7020 MFF i5 16GB
Dell OptiPlex 7020 Micro Form Factor, Intel i5-14600T, 16GB RAM, 512GB SSD
Configured for Zonal RDP solutions.
Product Details
| General |
CPU |
14th Generation Intel Core i5- 14600T (6+8 Cores/24MB/20T/1.8GH z to 5.1GHz/35W) |
| RAM | 16GB, 1 x 16GB, DDR5 (2 x SODIMM, 262 Pin, Slots available) | |
| Storage | M.2 2280 512GB PCIe NVMe SSD Class 40 | |
| Operating System | Windows 10 IOT LTSC 2021 Value | |
| Connectivity |
1 x USB 3.2 Gen 1 (5 Gbps) port with PowerShare (Front) 1 x USB 3.2 Gen 2 (10 Gbps) Type-C port (Front) 1 x USB 2.0 port (480 Mbps) with Smart Power On (Rear) 2 x USB 3.2 Gen 1 (5 Gbps) ports (Rear) 1 x USB 2.0 (480 Mbps) port (Rear) 1 x RJ-45 Ethernet port 10/100/1000 Mbps 1 x DisplayPort 1.4a 1 x HDMI 1.4b port 1 x Line In/Out, Universal Audio Jack (Front) |
|
| Display Interface | Integrated Intel UHD Graphics 770 on shared system memory | |
| Security |
1 x Kensington lock slot 1 x Padlock ring |
|
| Physical | Dimensions | 36 x 178 x 182 (1.42 x 7.00 x 7.17in) |
| Weight | 1.32 kg (2.91 lbs.) maximum | |
| Power | External Adaptor |
Input: 90W, 100-240Vac, 50 - 60Hz, 1.5A Output: 19.5 Vdc,4.62A, ENV0424 compliant |
| Environmental | Operating |
10 °C to 35 °C (50 °F to 95 °F) 20% to 80% (non-condensing, Max dewpoint temperature = 26°C) Altitude Range: -3048 m (10,000 ft) |
| Storage |
-40°C to 65°C (-40°F to 149°F) 5% to 95% (non-condensing, Max dewpoint temperature = 33°C) Altitude Range: 10,668m (35,000 ft) |
|
| Certifications | - |
See Documentation section RoHS |
| Box Contents | Contents |
Dell OptiPlex 7020 MFF Wired Dell Keyboard (UK) and mouse 90W Power Adaptor UK Power Cord |
| Weight | 3kg (6.6 lbs) |
Images
Documentation
| Source | Information |
|---|---|
| Product Web Page | Dell Technologies OptiPlex 7010 MFF |
| Manuals | Owners Manual OptiPlex 7010 MFF |
| Regulatory Information |
Dell Regulatory Compliance Home Page Responsible Business Alliance policy |
| Carbon Footprint | Dell Technologies OptiPlex 7020 MFF |
Accessories & Spares
| Item | Part Number | Status |
|---|---|---|
| Power Supply, 100-240Vac, 50-60Hz, for Optiplex PC's,90W | PCDELL-PSU-90W | • Active |
| 16GB Memory Module DDR5, SoDIMM 262pin, 5600 MHZ | PCDIMM16GB-DDR5 | • Active |
| 32GB memory Module, DDR5, SoDIMM 262-pin, 5600MHz | PCDIMM32GB-PC5A | • Active |
