PC350P
Dell Optiplex XE4 SFF i7 16GB
Dell OptiPlex XE4 Small Form Factor, Intel i7-12700T, 16GB RAM, 512GB SSD
Premium, high performance, industrial grade PC.
Product Details
| General |
CPU |
12th Generation Intel® Core™ i7-12700T (12 Cores/25MB/20T/2 .1GHz to 4.9GHz/65W) |
| RAM | 16GB, 1 x 16GB, DDR4 3200 MHz(4 UDIMM available) | |
| Storage | 512GB, M.2 2230, PCIe NVMe, SSD, Class 35 | |
| Operating System | - | |
| Connectivity |
1 x USB 2.0 port with PowerShare (front) 1 x USB 2.0 port (front) 1 x USB 3.2 Gen 2 port (front) 1 x USB 3.2 Gen 2x2 Type-C port (front) 3 x USB 3.2 Gen 1 ports (rear) 1 x USB 3.2 Gen 2 port (rear) 2 x USB 2.0 ports with Smart Power On (rear) 1 x RJ-45 Ethernet port 10/100/1000 Mbps 3 x DisplayPort 1.4 port 1 x VGA Port 1 x One Universal audio port (front) 1 x One re-tasking line-out/line-in audio port (rear) 2 x Expansion Slots |
|
| Display Interface | Intel UHD Graphics 770 on shared system memory | |
| Security |
- |
|
| Physical | Dimensions | 292 x 290 x 92 mm (11.42 x 11.53 x 3.65in) |
| Weight | 5.63 kg (12.42 lb) Maximum | |
| Power | Internal Power |
300 W (92% Efficient, 80 PLUS Platinum) 90 VAC - 264 VAC 47 Hz - 63 Hz 4.2A |
| Environmental | Operating |
5°C–45°C (41°F–113°F) 20% to 80% (non-condensing, Max dewpoint temperature = 26°C) Altitude Range: 3048 m (10,000 ft) |
| Storage |
-40°C to 65°C (-40°F to 149°F) 5% to 95% (non-condensing, Max dewpoint temperature = 33°C) Altitude Range: 10,668 m (35,000 ft) |
|
| Certifications | - |
EPEAT , ENERGY STAR , US CEC MEPS, Australia and New Zealand MEPS,CEL, WEEE Japan Energy Law, South Korea E-standby, EU RoHS, China RoHS |
| Box Contents | Contents |
Dell Optiplex EX4 SFF Wired Dell Keyboard (UK) and mouse UK Power Cord |
| Weight | 8Kg (17.7lbs) |
Images
Documentation
| Source | Information |
|---|---|
| Product Web Page | Dell Technologies OptiPlex XE4 SFF |
| Product Specification Page | Dell Technologies OptiPlex XE4 SFF Setup and Specification |
| Carbon Footprint | Dell Technologies OptiPlex XE4 SFF |
Accessories & Spares
| Item | Part Number | Status |
|---|---|---|
| 8GB memory Module, DDR4, DIMM 288-pin, 2666MT/s (PC4-21300) | PCDIMM8GB-PC4B | • Active |
| 16GB memory Module, DDR4, DIMM 288-pin, 2666MT/s (PC4-21300) | PCDIMM16GB-PC4B | • Active |
| UK Mains Lead to IEC Kettle Plug Straight | LD4010 | • Active |
