• End of Life

Release Date: 1 January 2023

PC360PMAB

Dell OptiPlex 7010 MFF i7 16GB

Dell OptiPlex 7010 Micro Form Factor, Intel i7-13700T, 16GB RAM, 256GB SSD

Sections

Product Details

General

CPU

 13th Generation Intel® Core™ i7-13700T (8+8 Cores/30MB/24T/1.4GHz to 4.8GHz/35W)
RAM 16GB, 1 x 16GB, DDR4, 2666/2933/3200 MHz (2 x SODIMM, 260 Pin, Slots available)
Storage 256GB, M.2 2230, PCIe NVMe, SSD, Class 35
Operating System

-
Connectivity

2 x USB 3.2 Gen 1 Type-A port (Front)

1 x USB 2.0 Type-A port (Rear)

1 x USB 2.0 Type-A port with Smart Power On (Rear)

2 x USB 3.2 Gen 1 Type-A ports (Rear)

1 x RJ-45 Ethernet port 10/100/1000 Mbps

1 x DisplayPort 1.4 port

1 x HDMI Port 1.4b

1 x Line In/Out 4. Universal Audio Jack
Display Interface Integrated Intel UHD Graphics 770 on shared system memory
Security 1 x Kensington lock slot 1 x Padlock ring
Physical Dimensions 36 x 178 x 182 (1.42 x 7.00 x 7.17in)
Weight 1.33 kg (2.94 lbs)
Power External Adaptor

Input: 90W, 100-240Vac, 50 - 60Hz, 1.5A

Output: 19.5 Vdc, 4.62A, ENV0424 compliant
Environmental Operating

10 °C to 35 °C (50 °F to 95 °F)

20% to 80% (non-condensing, Max dewpoint temperature = 26°C)

Altitude Range: 3048 m (10,000 ft)
Storage

-40°C to 65°C (-40°F to 149°F)

5% to 95% (non-condensing, Max dewpoint temperature = 33°C)

Altitude Range: 10,668m (35,000 ft)
Certifications -

EPEAT , ENERGY STAR , US CEC MEPS, Australia and New Zealand MEPS,CEL, WEEE Japan Energy Law, South Korea E-standby, EU RoHS, China RoHS
Box Contents Contents

Dell Optiplex 7010 MFF

Wired Dell Keyboard (UK ) and mouse

90W Power Adaptor

UK Power Cord
Weight 3Kg (6.6 lbs)

Images





Documentation

Source Information
Product Web Page Dell Technologies OptiPlex 7010 MFF
Product Specification Page Dell Technologies OptiPlex 7010 Series MFF Setup and Specification

Accessories & Spares

Item Part Number Status
Power Supply, 100-240Vac, 50-60Hz, for Optiplex PC's, 90W PC-PSU-90W • Active
8GB memory Module, DDR4, SO-DIMM 260-pin, 3200MHz PCDIMM8GB-DDR4 • Active
16GB memory Module, DDR4, SO-DIMM 260-pin, 3200MHz PCDIMM16GB-DDR4 • Active
